Small Water Boring Machine

A small water boring machine is a compact drilling solution for finding and accessing groundwater. This small water boring machine fits rural homes, farms, and small projects where large rigs cannot work. It is simple to move, easy to operate, and cost-effective for shallow to medium wells.

What Is A Small Water Boring Machine

A small water boring machine is a small drill rig made to drill wells quickly in limited spaces.
Uses:

• Home water wells and small farms.
• Village clean water projects.
• Emergency and temporary water supply.

Working principle: the rig turns a drill bit to cut soil and rock. Drilling fluid or air removes cuttings. When the drill reaches water, the operator installs casing and a pump.

YG Portable Water Well Drilling Rig Features

YG portable water borewell machines have many user-friendly features. They work well in remote places and tight sites.

• Compact, light frame — easy to transport.
• Reliable diesel or electric power options.
• Low fuel use and stable drilling speed.
• Easy control panel for quick learning.
• Strong drill head and bits for mixed soils.

Technical Specifications of Small Water Boring Machine

Model	HY180	HY240	HY350	ZX280	HY500
Voltage	220V	220V	380V	gasoline/diesel	380V
Power	1.5-2kw	4kw	3kw	8HP	5.5kw
Drilling hole	80-200mm	80-220mm	80-350mm	80-280mm	80-500mm
Drilling depth	80M	100M	100M	120M	120M
Drilling rod	Φ42mm,1.5m	Φ51mm,1.5m	Φ51mm,1.5m	Φ51mm,1.5m	Φ65mm,2m
Pump power	2.2kw	2.2kw	2.2kw	3.5HP	5.5kw
Dimension	0.7*0.7*2.5m	0.7*0.7*2.5m	0.8*0.8*2.7m	0.8*0.8*2.7m	1*1.5*2m
Weight	120KG	150KG	250KG	200KG	600KG

Applications Of Home Water Bore Drilling Equipment

YG mini borehole drilling machines help many projects:

• Rural community water supply.
• Agricultural irrigation wells.
• Household wells for drinking and domestic use.
• Geotechnical tests and small foundation borings.

Key benefits for these uses:

• Fast setup and drilling.
• Lower cost than big rigs.
• Good for hard-to-reach or narrow sites.

Advantages Of A Low-Cost Water Well Drilling Machine

Choosing a small water boring machine brings clear wins:

• Cost Savings: lower purchase and transport costs.
• Flexibility: a portable water well drilling rig can move between sites.
• Speed: quick to drill shallow wells, the job finishes sooner.
• Energy Choice: diesel or electric for site needs.

YG machines are designed for long life and low maintenance. Spare parts are easy to get, and training is simple.

How To Choose A Mini Water Drilling Rig For Sale

Follow these steps to pick the right unit:

1. Decide drill depth needed for your water table.
2. Check local soil types — soft, clay, gravel, or rock.
3. Choose power: diesel for off-grid sites, electric where power exists.
4. Consider mobility: trailer, skid, or carrier mount.
5. Ask YG for advice based on your project size and budget.

Why Choose YG Small Water Boring Machine

YG has 20+ years in drilling equipment. Customers choose YG because:

• Proven global projects in Africa, Asia, and Latin America.
• Strong parts and tested components for long life.
• Competitive factory price with good value.
• Full after-sales: spare parts, remote help, and field training.

Customer Feedback And Case Examples

Many clients report fast results and reliable machines. Example: a village in Tanzania used YG-180 to drill five wells in two weeks. The wells supply clean water to 600 people. Farmers report better crops after irrigation started.

Contact YG For Your Water Project

If you need a small water boring machine for home or a community, contact YG. Tell us your well depth, soil, and power option. We will recommend the best model and offer a clear quote.
