A Saudi Arabian solar contractor purchased a Photovoltaic Pile Driver for Sale from YG Machinery to support the construction of a large solar power plant, aiming to improve piling efficiency while reducing risks under harsh desert site conditions.
This project involved continuous piling work over a wide area, where equipment reliability, adaptability, and easy operation were critical to keeping the construction schedule on track.
Project Background And Site Conditions In Saudi Arabia
The project was a large-scale ground-mounted solar power plant, located in an open area with typical Saudi Arabian climate and soil conditions.
Site Environment Characteristics
Long-term high temperatures during the daytime
Sandy and semi-desert soil structure
Wide construction area with limited natural shelter
Project Constraints
Construction schedule affected by extreme heat
High demand for stable, continuous operation
Limited tolerance for frequent machine failure or downtime
Under these conditions, the client needed photovoltaic piling equipment that could work reliably for long hours without complex maintenance.
Client Requirements And Selection Logic
Before choosing YG Machinery, the client evaluated several possible solutions.
Core Goals
Improve piling efficiency for solar panel foundations
Reduce construction risks caused by unstable equipment
Compared Options
Local piling machines with limited drilling functions
Other imported machines with higher cost and complex operation
Key Questions From The Client
Can the machine adapt to sandy Saudi soil?
Is it reliable under high-temperature conditions?
Are transportation and after-sales support manageable?
Only equipment that could clearly answer these concerns was considered for final selection.
Why A Photovoltaic Pile Driver Was Chosen
After comparison, the client decided that a solar pile driving machine designed specifically for photovoltaic projects was more suitable than general piling equipment.
Decision Logic
Designed for solar foundation piling
Supports different pile types and sizes
Combines piling and drilling functions
Higher efficiency than general-purpose machines
This PV pile driver allowed the contractor to handle varying ground conditions without switching machines, which helped simplify site management.
After evaluating different equipment options and discussing performance suitability, site conditions, and operational constraints, the client made a procurement decision and selected the following photovoltaic pile driver configuration for the project.
1. Pile Driver
Item
Specification
Hammer Drill Bit
Included
Rotary Drill Bit
Included
Max Drilling Depth
3 meters
Max Drilling Diameter
300 mm
Max Drilling Speed
2 m/min
Dimension (L × W × H)
3100 × 2250 × 2350 mm
Weight
3200 kg
Engine Power
39 kW
Drilling Angle Range
Left 10°, Right 10°
Front 15°, Back 15°
Climbing Angle
25°
Walking Speed
2 km/h
2. Air Compressor
Item
Specification
Air Pressure
15 bar
Air Flow Rate
15 m³/min
Dimension (L × W × H)
3250 × 1610 × 2250 mm
Weight
2520 kg
Engine Power
141 kW
3. Accessories
Item
Specification
Spiral Drill Bit
Diameter 300 mm
DTH Drill Bit
Diameter 200 mm
Impact Hammer
Diameter 200 mm
Drilling Pipe
Diameter 89 mm, Length 3 meters
Delivery Process And Export To Saudi Arabia
YG Machinery focused on delivery readiness rather than simple transportation.
Key Support Actions
Reinforced export packaging for long-distance transport
Heat-resistant protection measures
Controlled shipping schedule to match site planning
Provided technical manuals and remote guidance
This approach helped ensure the equipment could be put into use quickly after arrival.
