A Mini Track Skid Steer is a compact and versatile loader designed for work in tight areas and uneven ground. Instead of wheels, it uses rubber tracks for better stability and traction. It’s perfect for construction sites, landscaping, agriculture, snow removal, and material handling in warehouses.
This machine uses a hydrostatic transmission system that allows zero-radius turning, making it extremely easy to maneuver even in small spaces.
Key Features of YG Mini Track Skid Steer
The YG Mini Track Skid Steer is built for performance, efficiency, and comfort. Its design focuses on versatility and durability to handle multiple jobs in different environments.
Main features include:
- Compact Size: Works efficiently in narrow spaces and indoor areas.
- Strong Hydraulic Power: Ensures smooth lifting and loading.
- Rubber Tracks: Reduce ground damage and improve traction on soft or uneven terrain.
- Quick-Attach System: Supports different attachments such as buckets, augers, forks, and trenchers.
- Operator Comfort: Ergonomic control layout and wide visibility enhance safety and ease of use.
Technical Specifications of Mini Track Skid Steer
YG’s Mini Track Skid Steer comes with various models to meet different project needs.
Typical specifications:
| em | YG280 | YG380 | YG380C | |||
| With Rubber Track | With Chevron Engineering Tyre | With Chevron Engineering Tyre | ||||
| Metric | The U.S. | Metric | The U.S. | Metric | The U.S. | |
| Max working height(H3) | 2065mm | 81.3inch | 2143mm | 84.37inch | 2143mm | 84.37inch |
| Max pin height(H2) | 1803mm | 71inch | 1884mm | 74.17inch | 1884mm | 74.17inch |
| Max Dumping height(H1) | 1386mm | 54.6inch | 1488mm | 58.58inch | 1488mm | 58.58inch |
| Max Dumping distance(E) | 471mm | 18.5inch | 348mm | 13.7inch | 348mm | 13.7inch |
| Max Dumping Angle(a3) | 32° | 32° | 30° | 30° | 30° | 30° |
| Rollback of the bucket on the ground(a2) | 33° | 33° | 25° | 25° | 25° | 25° |
| Departure angle(a1) | 18° | 18° | 11° | 11° | 16° | 16° |
| Total height(H) | 1309mm | 51.5inch | 1233mm | 48.54inch | 1265mm | 50inch |
| Ground clearance(F) | 123mm | 4.8inch | 118mm | 4.65inch | 118mm | 4.65inch |
| Wheelbase(L1) | 690mm | 27.2inch | 636mm | 25.0inch | 636mm | 25.0inch |
| Overall length without bucket(L3) | 1778mm | 70inch | 1752mm | 69.0inch | 1980mm | 78inch |
| Total width(W) | 800mm | 31.5inch | 1160mm | 45.67inch | 1160mm | 45.67inch |
| Bucket width(B) | 820mm | 32.3inch | 980mm | 38.6inch | 980mm | 38.6inch |
| Total length with bucket(L) | 2210mm | 87inch | 2206mm | 86.9inch | 2430mm | 95.7inch |
| Turn radius forward turning(R) | 1237mm | 48.7inch | 1307mm | 51.5inch | 1307mm | 51.5inch |
Each compact skid steer loader is built with a strong steel frame and high-quality hydraulic components to ensure reliability and long service life.
Advantages Of Using A Mini Track Skid Steer
Using a YG Mini Track Skid Steer brings many benefits for both small contractors and large projects:
- Works efficiently in tight or rough areas.
- Easy to operate with intuitive controls.
- Supports many attachments for various tasks.
- Saves labor and improves productivity.
- Lower maintenance cost compared to larger machines.
This mini skid steer for sale offers the perfect balance between power and size, making it a great choice for operators who need flexibility.
Industry Applications of Small Track Skid Loader
The YG small track skid loader is widely used in:
- Construction: Earthmoving, trenching, site cleaning.
- Landscaping: Grading, soil leveling, and debris removal.
- Agriculture: Feeding livestock, cleaning barns, handling hay.
- Snow Removal: Clearing roads and sidewalks in winter.
- Warehouse: Moving heavy materials with pallet forks.
Its compact design and strong hydraulic system make it an all-around performer in multiple industries.
How To Choose The Right Mini Track Skid Steer
When selecting a Mini Track Skid Steer, consider the following:
- Job Type: Choose engine power based on task intensity.
- Ground Conditions: Tracks with a stronger grip for muddy or rocky areas.
- Attachments Needed: Ensure compatibility with your tools.
- Budget: Compare models by their mini track skid steer price and long-term value.
YG experts can recommend the most suitable model according to your working environment and requirements.
Why Choose YG Machinery As Your Supplier
YG Machinery is a trusted manufacturer of compact and heavy equipment. Besides Mini Track Skid Steer, YG also provides:
- Wheel skid steer loaders
- Mini Excavators
- Small Concrete Mixers
- Road rollers
YG offers full technical support, fast delivery, and customized options to meet your business needs. The machines are CE-certified and built to perform in demanding conditions.
Frequently Asked Questions (FAQ)
Q1: What engine does the YG Mini Track Skid Steer use?
A: It is powered by a reliable diesel engine with stable output and low fuel consumption.
Q2: Can the skid steer use multiple attachments?
A: Yes, it can be equipped with different attachments like augers, buckets, forks, and sweepers.
Q3: How do I maintain my skid steer?
A: Regularly check hydraulic oil, track tension, and filters to ensure long-term performance.
Q4: What is the delivery time?
A: Usually 7–15 working days after order confirmation.
